Features
| 109 dB sensitivity |  | ||
 500-18000 Hz response | |||
| 75mm(3.0 in) Aluminium voice coil | |||
| 220W continuous program power capacity | |||
Specificatians
| TYPE | ND HF DRIVER | Frequency Range | 500-18000 (Hz) | |
| Throat Diameter | 36/1.4 (mm/in) | Recommended Crossover | 1000 (Hz) | |
| Rated Impedance | 8 (ohm) | Voice Coil Diameter | 75/3.0 (mm/in) | |
| Minimum Impedance | 8.9 (ohm) | Winding Material | Aluminium | |
| Nominal Power Handling | 110 (Watts) | Former Material | Kapton | |
| Continuous Power Handling | 220 (Watts) | Diaphragm Material | Titanium | |
| Sensitivity | 109 (dB) | Magnetic Material | Neodymium Ring |
Mounting And Shipping
| Overall Diameter | 132/5.19 (mm/in) | N.W.（1 pc） | 2.95 / 6.5 (kg/lb) | |
| Driver Depth | 62/2.44 (mm/in) | G.W.（6 pcs） | 17.9 / 39.4 (kg/lb) | |
| Four M6 holes 90° on 102 mm diameter | 4 x M6 -102 -90° | Shipping size（6 pcs） | 420x320x100 (mm) |
