| Impedance: | |
|---|---|
| Quantity: | |
Features
| 96 dB sensitivity |  | ||
 30-1000 Hz response | |||
| 152mm(6.0 in) copper voice coil | |||
| 2000W continuous program power capacity | |||
Specificatians
| TYPE | FE SUBWOOFER | Frequency Range | 30-1000 (Hz) | |
| Nominal Diameter | 530/21 (mm/in) | Voice Coil Diameter | 152/6.0 (mm/in) | |
| Rated Impedance | 8 (ohm) | Winding Material | Copper | |
| Minimum Impedance | 7.7 (ohm) | Former Material | Glass Fibre | |
| AES Power Handing | 2000 (Watts) | Winding Depth | 32.5/1.27 (mm/in) | |
| Peak Power Handing | 4000 (Watts) | Magnetic Gap Depth | 12/0.47 (mm/in) | |
| Sensitivity | 96 (dB) | Magnetic Material | Ferrite Ring |
Thiele & Small Parameters
| Fs | 32 (Hz) | Mms | 442 (g) | |
| Re | 6 (ohm) | Vas | 217 (liters) | |
| Qms | 11 | Sd | 1676 (cm2) | |
| Qes | 0.58 | L1kHz | 2.42 (mh) | |
| Qts | 0.55 | Xmax | ±13 (mm) | |
| Bl | 30 (T.M) | EBP | 55 (Hz) |
Mounting And Shipping
| Overall Diameter | 550/ 21.6 (mm/in) | Flange And Gasket Thickness | 15/ 0.59 (mm/in) | |
| Bolt Circle Diameter | 528/ 20.7 (mm/in) | N.W. (1 pc) | 24.8 / 54.6 (kg/lb) | |
| Mount Baffle Cut-out | 506/ 19.9 (mm/in) | G.W. (1 pc) | 30.6 / 67.4 (kg/lb) | |
| Speaker Depth | 241/9.88 (mm/in) | Shipping Size (1 pc) | 640x610x350 (mm) | |
| Mounting Hole | 8 |
